Higher working pressure may be achieved with different actuator. Please consult a SED factory representative for working pressure above the indicated maximum.
Max. working temperature：160°C (320°F) dependent on application
Control pressure：Cf. 1 & 4 DN 15-50 4,5 - 8 bar(65-115 psi)
        Cf. 1 & 4 DN 65-80 5 - 8 bar(72-115 psi)
        Cf. 1 & 4 DN 100 6 - 8 bar(87-115 psi)
        Cf. 1 & 4 DN 65-80 5 - 8 bar(72-115 psi)
        Cf. 2, 3, 5 & 6 DN 15-80 4,5-6 bar(65-87 psi)
        Cf. 2, 3, 5 & 6 DN 100 5,5-7 bar(80-100 psi)
Diaphragm material：EPDM or PTFE
Valve body material：Forged 1.4435/ 316 L ASME/BPE
         Forged 1.4435/ 316 L ASME/BPE
         Investment cast 1.4435/ 316 L
         Other alloys
End connection：Butt weld ends see fold out page 21
         Clamps and flanges see page 22 and 23
        Special ends
Actuators suitable for：Two-Way bodies
            Welded configurations
           T-bodies
           Multiport bodies
           Tank bottom bodies
Flow rate：Kv in m3/h (Cv in GPM) see page 9
     MA see table below
     Technical data also valid for multiport valve.
